8-Drawer Built-In Freezer, Model SIFNAe 5188, Liebherr

Model Type

Fully Integrated Freezer with IceTower and AutoDoor

Global Trade Item Number (GTIN)

4016803115670

Series

Peak

Energy Efficiency Rating

D

Annual Energy Consumption

190 kWh/year

Climate Class

SN-T

Noise Level

33 decibels

Voltage

220–240 volts ~

Frequency

50–60 Hz

Connection rating

1.3 amps, 186 watts

Coolant

R 600a

Control

2.4-inch color TFT display, touchscreen and swipe

Control Unit

Touch and swipe

Number of Temperature Zones

1

Number of regulated cooling circuits

1

Temperature display

Freezer

Super Cool

—

Superfrost

—

Door Alarm, Freeze

Adjustable on the device and via the app

Bottle timer

—

Ice cube timer

—

Night mode

—

Display Lock

Adjustable on the device

Connectivity Solution *

Integrated, fixed

Freezer compartment temperature range

15–28 degrees Celsius

Defrost Method

Automatic

Storage time in case of malfunction according to GS **

9:00 ​

Freezing capacity within 24 hours according to GS standard **

12.00 kg / 24 hours

Number of drawers in the freezer compartment

8

FrostSafe

Drawers enclosed on all sides with a transparent front

Drawer pull-out system, freezer compartment

Partially extendable telescopic rails

Interior lighting, freezer compartment

LED lighting

VarioSpace

✔

Pipe type

Main water line with WaterStop

Safe IceMaker Lighting

✔

Ice production

0.80 kg / 24 hours

Ice Storage

5.7 kg

Ice Tower

✔

Ice cube tray

—

Number of ice cube trays

0

Number of water filters

0

Number of refrigerated storage bins

1

Freezer tray

1

Star rating

4

Water Inlet

Permanent water connection

Dry Back Panel

—

Internal Back Wall Material

—

Interior Door Design

—

Material of the adjustable shelves in the freezer compartment

Glass

Installation Type

Designed for combined use

Door Installation

Fixed Door

Maximum weight of a single kitchen cabinet door

26

Door hinges

Right

Door Hinge Replacement

Possible only through customer service

Door Opening Angle

115°

Door seal

Replaceable

Height-adjustable legs

2

Leveling rods

✔

Number of leveling rods

2

Ventilation

Ventilation grilles

Connecting cable (length)

2,200 mm

External Dimensions: Height/Width/Depth

177 / 55.9 / 54.6 cm

Capacity, Freezer Compartments

213 liters

Of which 4-star compartment

213.3 liters

Dimensions (Height/Width/Depth)

177.7–179.3 / 56–57 / 55.0 cm

External dimensions: Height/Width/Depth (with packaging)

1,829.0 / 585.0 / 622.0 mm

Weight (without packaging)

75.90 kg

Weight (with packaging)

80.00 kg

Total capacity ***

213 liters
