Liebherr ICNe 5103 Bottom-Freezer Refrigerator, Model ICNe 5103

Model Type

Combined Refrigerator-Freezer with EasyFresh and NoFrost

Global Trade Item Number (GTIN)

4016803116875

Series

Pure

Energy Efficiency Rating

The

Energy consumption over 24 hours

0.621 kWh / 24 hours

Annual Energy Consumption

227 kWh/year

Climate Division

SN-T

Noise Level

34 decibels

Sound Emission Level

B

Voltage

220–240 volts ~

Frequency

50–60 Hz

Connection Rating

1.4 amps, 183 watts

Control

Monochrome LCD, touchscreen

Control Unit

Touch

Number of temperature zones

2

Number of regulated cooling circuits

2

Temperature display

Refrigerator and freezer compartments

Super Cool

—

Superfrost

—

Door Alarm, Cooling

Can be adjusted on the device and via the app

Door alarm, freeze

Can be adjusted on the device and via the app

Bottle timer

—

Connectivity solution *

Reusable

Ice cube timer

—

Night Mode

—

Display Lock

Adjustable on the device

Adjustable temperature range

+2°C to +9°C

Humidity control

Dual cooling

Climate zones in the refrigerator compartment

Easy Fresh

Versatile uses: safe for fruits and vegetables or for meat and dairy products

1

Defrosting Method

Automatic

Forced-air cooling

✔

FreshAir Filter

Inside the fan housing

Removable system drawer, cooling compartment

Integrated drawer guide

SoftSystem

—

Refrigerated compartment Lighting

Ceiling-mounted LED lighting

Number of Storage Shelves, Refrigerated Compartment

4

of which are separable

0

Of which are height-adjustable

3

VarioSafe

—

OpenStage drawers

—

Bottle Storage

—

Bottle Holder

1

Number of can shelves

2

VarioBox

—

VarioBoxes

0

Butter plate

—

Egg tray

10 eggs

Door Shelf Type Refrigerator Compartment

Bottle and can holder

Height-adjustable interior door shelf

Stepless adjustment

Adjustable temperature range

15–26 degrees Celsius

Freezer Compartment Location

Bottom

Defrost method

Automatic

Storage time in case of malfunction according to GS **

9:00 ​

Freezing capacity within 24 hours according to GS standard **

6.00 kg / 24 hours

Number of drawers in the freezer compartment

3

FrostSafe

Drawers enclosed on all sides with a transparent front

Drawer pull-out system, freezer compartment

Drawer on safety glass

Interior lighting, freezer compartment

—

4-star freezer door

—

Number of glass shelves, 4-star freezer compartment

0

VarioSpace

✔

Safe lighting for the IceMaker

—

Water Inlet

—

Ice Tray

—

Number of ice cube trays

0

Number of water filters

0

Number of refrigerated storage bins

0

Freezer tray

0

Star Rating

4

Dry Back Panel

—

Internal Back Wall Material

—

Interior Door Design

—

Interior door shelf material

White plastic

Storage Shelf and Refrigerator Compartment Material

Glass

Material of the adjustable shelves in the freezer compartment

Glass

Door material

Steel

Installation Type

Designed for combined use

Door Installation

Fixed Door

Maximum weight of a single kitchen cabinet door

18/12

Door hinges

Right

Door Hinge Replacement

Possible for the customer

Door Opening Angle

115°

Door seal

Replaceable

Height-adjustable legs

2

Leveling rods

✔

Number of leveling rods

2

Ventilation

Ventilation grilles

Frame design

—

Plug Type

Yoro

Connecting Cable (Length)

2,200 mm

Dimensions (Height/Width/Depth)

177.2–178.8 / 56–57 / 55.0 cm

External Dimensions: Height/Width/Depth (with packaging)

1,829.0 / 585.0 / 622.0 mm

External Dimensions: Height/Width/Depth

177 / 55.9 / 54.6 cm

Weight (without packaging)

59.30 kg

Weight (with packaging)

62.70 kg

Total capacity ***

253 liters

Volume, refrigeration compartments

183 liters

Freezer compartment capacity

70 liters

Of which 4-star compartment

69.9 liters

Of which 4-star compartment

69.9 liters

Refrigerator compartment

182 liters

Freezer compartment

69 liters
