LIEBHERR ICNSd 5603 Bottom-Freezer Refrigerator, Integrated Model

Model Type

Combined Refrigerator-Freezer with EasyFresh and NoFrost

Global Trade Item Number (GTIN)

4016803137399

Series

Pure

Energy Efficiency Rating

D

Energy Consumption in 24 Hours

0.493 kWh / 24 hours

Annual Energy Consumption

180 kWh/year

Climate Class

SN-T

Noise level

33 decibels

Sound Emission Level

B

Voltage

220–240 volts ~

Frequency

50/60 Hz

Connection Rating

1.4 amps, 183 watts

Control

Monochrome LCD display, touchscreen

Control Unit

Touch

Number of temperature zones

2

Number of regulated cooling circuits

2

Temperature display

Refrigerator and freezer compartments

Super Cool

—

Superfrost

—

Door Alarm, Cooling

Can be adjusted on the device and via the app

Door alarm, freeze

Can be adjusted on the device and via the app

Bottle timer

—

Connectivity solution *

Reusable

Ice cube timer

—

Night Mode

—

Display Lock

Adjustable on the device

Adjustable temperature range

+2°C to +9°C

Humidity control

Dual cooling

Climate zones in the refrigeration compartment

Easy Fresh

Versatile uses—safe for fruits and vegetables or for meat and dairy products

1

Defrosting Method

Automatic

Forced-air cooling

✔

FreshAir Filter

Inside the fan housing

Removable system drawer, cooling compartment

Integrated drawer guide

SoftSystem

—

Refrigerated compartment Lighting

Ceiling-mounted LED lighting

Number of Storage Shelves, Refrigerated Compartment

5

Of which are separable

0

Of which are height-adjustable

4

VarioSafe

—

Bottle Storage

Bottle rack

Bottle Holder

1

Number of can shelves

3

VarioBox

—

VarioBoxes

0

Butter Plate

—

Egg tray

10 eggs

Door Shelf Type: Refrigerator Compartment

Bottle and Can Holder

Height-adjustable interior door shelf

Stepless adjustment

Adjustable temperature range

15–26 degrees Celsius

Freezer Compartment Location

Bottom

Defrost method

Automatic

Storage time in case of malfunction according to GS **

9:00 ​

Freezing capacity within 24 hours according to GS standard **

6.00 kg / 24 hours

Number of drawers in the freezer compartment

3

FrostSafe

Drawers enclosed on all sides with a transparent front

Drawer pull-out system, freezer compartment

Drawer on safety glass

Interior lighting, freezer compartment

—

Number of glass shelves, 4-star freezer compartment

0

VarioSpace

✔

Pipe type

—

Water Inlet

—

Ice tray

—

Number of ice cube trays

0

Number of water filters

0

Number of refrigerated storage bins

0

Freezer tray

0

Star Rating

4

Dry Back Panel

—

Internal Back Wall Material

—

Interior Door Design

—

Interior door shelf material

White plastic

Storage Shelf and Refrigerator Compartment Material

Glass

Material of the adjustable shelves in the freezer compartment

Glass

Installation Type

Designed for combined use

Door Installation

Sliding Door

Door Hinges

Right

Replacing a door hinge

Can be done by the customer

Door Opening Angle

115°

Door seal

Replaceable

Height-adjustable legs

2

Leveling legs

✔

Number of leveling rods

2

Ventilation

Ventilation slats

Plug type

Yoro

Connecting Cable (Length)

2,200 mm

Aperture Dimensions (Height/Width/Depth)

194–195 / 56–57 / 55.0 cm

External Dimensions: Height/Width/Depth (with packaging)

1,996.0 / 555.0 / 622.0 mm

External Dimensions: Height/Width/Depth

193.8 / 54.1 / 54.5 cm

Weight (without packaging)

61.50 kg

Weight (with packaging)

65.30 kg

Total capacity ***

284 liters

Volume, refrigeration compartments

215 liters

Freezer compartment capacity

70 liters

Of which 4-star compartment

69.9 liters

Of which 4-star compartment

69.9 liters

Refrigerator compartment

215 liters

Freezer compartment

70 liters
