Miele KMDA 7876 FL-U Induction Cooktop with Built-in Range Hood

KMDA 7876 FL-UInduction Cooktop

80 cm wide induction cooktop

Details

Type
Induction cooktop with integrated range hood
Operating Modes
Ducted exhaust with optional accessories
DFK-xxxx, DMK 150-1
Recirculating with optional accessories
DFK-xxxx, DUU 1500, DUU 600
Unguided recirculation ( Plug & Play installation )

Design
Elegant glass-ceramic surface
Frameless—surface-mounted
Floor
Ceramic surface color
Matte black
Scratch-resistant surface
Matte finish
Anti-fingerprint effect
Flat-fit exhaust blower
Grille cover color
Black
Grease filter color
Black

Cooking Zone Details
Number of cooking zones
4
Number of cooking zones
2
Maximum number of pans
4

Flexible Cooking Zones
NO.
4
Type
PowerFlex XLcooking zone
Diameter in mm
Diameter 150–230
Rated Power (W)
2100
Booster Power (W)
3000
Twin Booster Power (W)
3650

Cooking Zone/First Cooking Zone
Mode
Left
Type
PowerFlex XLCooking Zone
Size in mm
230x460
Maximum rating in W
3400
Maximum booster power in W
4800
Maximum TwinBooster power rating in W
7300

Cooking Zone / Second Cooking Zone
Mode
Right
Type
PowerFlex XLcooking zone
Size in mm
230x460
Maximum power rating in W
3400
Maximum booster power in watts
4800
TwinBooster maximum power rating in watts
7300

User convenience
Operation via sensor controls
White ComfortSelect
Display color
White
Miele@home
Connectivity
Digital power level display
Fixed pan detection
Keep Warm
Stop-and-Go function
Memory function
Minute Timer
Safety Shut-Off
Automatic heating
Customizable settings (e.g., alarms)
Operating time:5/15 minutes.
Activated carbon filter saturation indicator

Efficiency
Energy efficiency class (A+++ to D)
A+
Annual energy consumption in kWh/year
31.3
Dynamic liquid efficiency class
A
Lighting efficiency rating
Not applicable
Grease filtration efficiency rating
A
Eco Motor
Quiet Motor

Cleaning and Maintenance
Easy-to-clean ceramic glass
Scratch Protection
Easy-to-clean hood interior – CleanCover
Quick cleaning of the range hood interior
Thorough cleaning of the range hood interior

Airflow
Airflow at minimum setting (m³/h) per EN 61591
205
Airflow at maximum setting (m³/h) per EN 61591
533
Airflow at intensive setting (m³/h) according to EN 61591
606
Sound level at minimum setting (dB(A) re 1 pW) according to EN 60704-3
41
Sound level at maximum setting (dB(A) re 1 pW) according to EN 60704-3
64
Sound level at booster setting (dB(A) re 1 pW) in accordance with EN 60704-3
68
Sound pressure at minimum level (dB(A) re 20 µPa) according to EN 60704-2-13
28
Sound pressure at maximum level (dB(A) re 20 µPa) according to EN 60704-2-13
51
Noise pressure level at peak intensity (dB(A) re 20 µPa) according to EN 60704-2-13
54

Cycle
Airflow at minimum level (m³/h) according to EN 61591
160
Airflow at maximum level (m³/h) according to EN 61591
475
Airflow at high level (m³/h) according to EN 61591
510
Sound level at minimum setting (dB(A) re 1 pW) according to EN 60704-3
46
Sound level at maximum setting (dB(A) re 1 pW) According to EN 60704-3
68
Intensive noise level (dB(A) re 1 pW) according to EN 60704-3
70
Minimum sound pressure level (dB(A) re 20 µPa) according to EN 60704-2-13
33
Maximum sound pressure level (dB(A) re 20 µPa) according to EN 60704-2-13
55
Noise pressure level at peak intensity (dB(A) re 20 µPa) according to EN 60704-2-13
57

Safety
Safety Shutdown
Lock function
System lock
Integrated cooling fan
Overheating protection
Residual heat indicator
Connection to a window contact switch

Technical Specifications
Dimensions (width x height x depth ) in mm
800 x 238 x 520
Dimensions in mm (width)
800
Dimensions in mm (height)
238
Dimensions in mm (depth)
520
Enclosure height including junction box in mm
238
Cutout dimensions in mm (width) with top-mounted installation
780 mm
Cutout dimensions in mm (depth) with top-mounted installation
500 mm
Internal cutting dimensions in mm (width) with top-mounted installation
780
Internal cutting dimensions in mm (depth) with top-mounted installation
500
External cutting dimensions in mm (width) with top-mounted installation
804
External cutting dimensions in mm (depth) with flat installation
524
Weight in kg
20
Total rated load in kilowatts
7,500
Voltage in V
230
Frequency in hertz
50–60
Power cord length in meters
1.4

Included accessories
Power cord
Yes
DKF 35-Pactivated carbon filter
Plug & Play adapter

EAN
EAN
4002516974581
